Technology


Featured Technology:  SAR Point Clouds



Neva Ridge has developed a new approach for calculating three-dimensional locations of pixels in SAR images.  Once determined, a "point cloud" can be constructed from this data.  These SAR Point Clouds provide unprecedented three-dimensional precision, and can be obtained in any weather, day or night, from long stand-off aircraft, unmanned aerial vehicles or even space.   This technology is in its infancy and will be an enabling capability for many applications going forward.

See our YouTube page for some examples:

3D Point Cloud generated from Air Force Research Lab Gotcha SAR data by Neva Ridge   PA Approval #:[88ABW-2017-0844]

3D Point Cloud generated from Air Force Research Lab Gotcha SAR data by Neva Ridge   PA Approval #:[88ABW-2017-0844]


SAR Interferometry

Neva Ridge has a complete compliment of traditional SAR interferometry tools for change detection, ground motion measurements (2-pass, 3-pass and PSI techniques) and elevation mapping.

Interferometric SAR Fringes reveal underlying topography.  Data source:  TerraSAR-X, Airbus

Interferometric SAR Fringes reveal underlying topography.  Data source:  TerraSAR-X, Airbus

SAR Point Clouds

A new technique for producing 3D point clouds from SAR data has been developed and demonstrated by Neva Ridge using a variety of SAR systems.

First demonstration of SAR Point Clouds, 2012

First demonstration of SAR Point Clouds, 2012

Change Detection

Change detection using SAR is known to be a very robust approach for monitoring regions.   Coherent (CCD), non-coherent (ACD) and polarimetric (PolCD) approaches have been implemented at Neva Ridge.

Registered CCD and ACD SAR product formed from a pair of SAR acquisitions.  Data source:  COSMO-SkyMed™ ASI

Registered CCD and ACD SAR product formed from a pair of SAR acquisitions.  Data source:  COSMO-SkyMed™ ASI

Image Formation

Neva Ridge has SAR Image Formation capabilities using a variety of algorithms including PFA, RMA and CBP.  These are implemented in both CPU and GPU environments.

Example SAR Image

Example SAR Image
